Aida HD-NDI-200
6 500 SEK
The conception of AIDA and NDI® – our first POV camera featuring NDI HX2 and HDMI together. From its formidable size
to easy connectivity, the HD-NDI-200 was designed as the perfect on-the-go NDI camera. Harness the power of NDI
through the first true POV experience AIDA has to offer.
to easy connectivity, the HD-NDI-200 was designed as the perfect on-the-go NDI camera. Harness the power of NDI
through the first true POV experience AIDA has to offer.
- Maila oss, vi svarar snabbt!
Information och specifikationer är vägledande och kan utan förvarning ändras av producenten. Alla uppgifter lämnas med reservation för tryckfel, och bilder är vägledande. Vissa texter kan vara autogenererade eller maskinöversatta och kan därför ge texter som kan vara missvisande.
- FärgN/A
Beskrivning
Art.nr: AID-HDNDI200
Main features
- Full-HD 1/2.86” Panasonic sensor capable of 1080 60p on NDI® HX2 & HDMI video
- Accessible Web UI to stream directly to social media platforms and control image parameters over IP
- Versatile design with top and bottom tripod mounts for unique shot creation
- OSD breakout cable provides power or control over serial RS485 communication
- Flawless relays multi-channel embedded audio via NDI® HX2
- Perfectly suited for new and existing NDI setups
Specifications
- Image Sensor – 1/2.86” Panasonic CMOS
- Sensor Size – 5.346mm x 3.336mm (16:9)
- Effective Pixels – Horizontal: 1920, Vertical: 1080
- Pixel Size – 2.75 μm (H) x 2.75 μm (V)
- Resolution – 1080p, 1080i, 720p
- Resolution Rate – 1080p: 60/59.94/50/30/29.97/25/24; 1080i: 60/59.94/50; 720p: 60/59.94/50/30/29.97/25
- Output – IP (NDI® HX2/SRT/RTMP/RTSP)
- IP Rate – 1920 x 1080 @ 3~60; 1280 x 720 @ 3~60; 1024 x 576 @ 3~60; 620 x 360 @ 3~60
- Color Space – 4:2:2 (YCbCr) 10bit
Lens
- Lens – 5MP 4mm CS Mount HD Lens | FOV: 86°
Audio
- Input – 3.5mm TRS Stereo Audio Port (IP ONLY)
- Sample Rate – 16/24/32 Bits
Physical
- Camera Control – VISCA RS485, VISCA over IP; OSD Buttons or Web UI
- Operation Temperature – 32°F - 104°F
- Dimension – 54mm x 54mm x 127mm / 2.125” x 2.125” x 5” (with default 4mm lens)
- Power – 12VDC (+9 - +15VDC)/POE
Packaging contents include
- PoE Dongle Adapter
- DC 12v Power Supply & Sockets Adapter
- 4mm Megapixels Lens (Pre-installed)
- USB Cable
- C-Mount Cap Adapter
- Sensor Cap
