Aida HD-NDI-CUBE
5 800 SEK
The flagship NDI® POV Series camera – showcasing the first broadcast-grade dedicated NDI® HX2 camera in the
market. Don’t let the HD-NDI-CUBE fool you. Its tiny form factor does not compromise any Full-HD quality seen in our
POV cameras. With the ability to output NDI HX2, SRT, RTSP, and RTMP simultaneously, it’s no wonder why the CUBE is
a production game-changer.
market. Don’t let the HD-NDI-CUBE fool you. Its tiny form factor does not compromise any Full-HD quality seen in our
POV cameras. With the ability to output NDI HX2, SRT, RTSP, and RTMP simultaneously, it’s no wonder why the CUBE is
a production game-changer.
- Maila oss, vi svarar snabbt!
Information och specifikationer är vägledande och kan utan förvarning ändras av producenten. Alla uppgifter lämnas med reservation för tryckfel, och bilder är vägledande. Vissa texter kan vara autogenererade eller maskinöversatta och kan därför ge texter som kan vara missvisande.
- FärgN/A
Beskrivning
Art.nr: AID-HDNDICUBE
Main features
- Full-HD 1/2.8” Sony CMOS sensor capable of 1080 60p on NDI® HX2
video - Accessible Web UI to stream directly to social media platforms and
control image parameters over IP - Versatile design with top and bottom tripod mounts for unique
shot creation - USB SVC port for easy network setting adjustments and updates
- Small form-factor makes it placeable in discreet places
- Perfectly suited as extra angles for any new or
- existing NDI® HX setup
Specifications
- Image Sensor – 1/2.8” Sony CMOS
- Sensor Size – 5.595mm x 3.23mm (16:9)
- Effective Pixels – Horizontal: 1920, Vertical: 1080
- Pixel Size – 2.9 μm (H) x 2.9 μm (V)
- Resolution – 1080p, 1080i, 720p
- Resolution Rate – 1080p: 60/59.94/50/30/29.97/25/24;
- 1080i: 60/59.94/50; 720p: 60/59.94/50
- Output – IP (NDI® HX2/SRT/RTMP/RTSP)
- Color Space – 4:2:2 (YCbCr) 10bit
- Min Illumination– 0.2Lux (day), 0.1Lux (night)
- White Balance – Auto & Manual (9,000 - 11,000 K)
Lens
- Lens – 5MP 4mm CS Mount HD Lens | FOV: 86°
Standard
- IP Protocol – UDP|IP, RTSP|RTMP, SRT, NDI® HX2
Physical
- Camera Control – VISCA over IP
- Operation Temperature – 32°F - 104°F
- Dimension – 86mm x 40mm x 40mm / 3.38” x 1.57” x 1.57” (with default 4mm lens)
- Weight – 180g / 0.39lbs (with default 4mm lens)
- Power – 12VDC (+9 - +15VDC) (PoE Adapter Included)
Packaging contents include
- NDI® POV CAMERAS
- PoE Dongle Adapter
- DC 12v Power Supply & Sockets Adapter
- 4mm 5MP Lens (Pre-installed)
- USB Cable
- C-Mount Cable Adapter
- Sensor Cap
